6000 cycle times 160Ah Prismatic Sodium Cell for energy storage
Main Feature of CSiT 160Ah sodium battery:
● Long cycle life. The cathode material we use is polynaion, cycle life is at lease 6000 times at 0.5C 80% DOD, which could provide 15 years service life for energy storage system.
● Super safe. The safety of sodium-ion batteries benefits from their excellent thermal stability of electrode materials, broad operating temperature range, and meticulously designed key components. These characteristics enable sodium-ion batteries to maintain stable performance under various extreme conditions.
● High quality. By adopting multi-stage rolling technology and the cooperation between the supporting mechanism and the rolling mechanism, the rebound phenomenon of the electrode sheet is effectively reduced, ensuring that the battery electrode sheet meets more stringent requirements for thickness uniformity.
● Good low temperature working performance. CSiT Sodium-ion batteries can operate normally within a temperature range of -40℃ to 80℃ and can still deliver more than 75% of their capacity at a low temperature of -40℃.
● No over discharge effect.
● Fast charge. Sodium ion cells can be charged at 3C, just 15 minutes, it will charge to 70% capacity.
Technical Datasheet
| Cell Model | CSC-50160118-HP70E |
| Nominal Voltage | 3.0V |
| Nominal Capacity | 160Ah |
| Dimension | 71.5*173.5*208mm |
| Inner Resistance | ≤0.65mΩ |
| Weight | 4.2±0.2kg |
| Cyle Life | ≥6000 times |
| Standard Charge Current | 0.5C |
| Standard Discharge Current | 0.5C |
| Max Con. Discharge Current | 2C |
| Pulse Discharge Rate | 3C |
| Dischage Cut-off Voltage | 1.5V |
| Shape | Prismatic |
| Charge Voltage | 3.8V |
| Battery Material | Sodium-ion |
| Charge Method | CC/CV |
| Charge Temperature | -10~55°C |
| Discharge Temperature | -40~60°C |
| Storage Temperature | Less than 1 month:15~40°C; Less than 6 months:15~30°C |
Application
CSiT sodium ion battery can be used for:
Energy storage system.
Communication based station.
E-mobility.
