liquid-cooled battery container for Commercial Battery Storage System
Advantages of CSiT liquid-cooled battery container
● High security: PACK-level precise fire protection, real-time fire detection, reserved water fire protection interface, multi-level security strategy.
● Multi-scenario application: supports multiple application scenarios such as peak shaving, demand-side response, emergency standby, etc.
● High reliability: high-quality battery cells from mainstream manufacturers, such as CATL, EVE, REPT, system-level verification, intelligent thermal management system, IP54 protection level.
● Intelligent platform: distributed access, unified management, providing intelligent monitoring and management platform, supporting mobile app and web use.
Technical Datasheet
| Item | Unit | Spec |
| Battery pack information | ||
| Cell type | \ | LFP 280Ah |
| Configuration | \ | 1P48S |
| Rated Voltage | Vdc | 153.6 |
| Working voltage range | Vdc | 134.4~175.2 |
| Rated energy | kWh | 43.008 |
| Charge/discharge rate | Cp | ≤0.5 |
| Battery cluster information | ||
| Battery pack QTY in series | \ | 8S |
| Rated Voltage | Vdc | 1228.8 |
| Working voltage range | Vdc | 1075.2~1401.6 |
| Rated energy | kWh | 344.064 |
| Charge/discharge rate | Cp | ≤0.5 |
| Battery system information | ||
| Battery cluster quantity | \ | 10 |
| Rated Voltage | Vdc | 1228.8 |
| Rated energy | kWh | 3440.64 |
| Charge/discharge rate | Cp | ≤0.5 |
| Cable output way | \ | DC convergence |
| General parameter | ||
| Dimension（W*D*H） | mm | 6058×2438×2896 |
| Weight | t | <35 |
| Working temperature range | ℃ | -30~55 |
| Relative humidity | %RH | 0~95%RH |
| Working altitude | m | ≤3000 |
| Cooling method | \ | liquid cooling |
| Protection Grade | \ | IP54 |
Product Overview
CSiT liquid cooled energy storage cabinet adopts standardized design, integrating the DC side of energy storage system such as lithium iron phosphate battery system, BMS, fire protection system, liquid cooling thermal management system and auxiliary power distribution into a 20-foot container. Advanced liquid cooling technology further improves product performance, energy density and cycle life, providing users with high-safety, high-reliability and long-life energy storage solutions, which can be flexibly configured to meet the needs of different application scenarios.
Application
The commercial and industrial ess is mainly used to provide electricity for factories, shopping malls, charging stations and microgrids.
